High Sensitivity And Fast Thermal Response NTC Temperature Sensor IP68 TPE Injection Overmolding

High Sensitivity And Fast Thermal Response NTC Temperature Sensor IP68 TPE Injection Overmolding
High Sensitivity And Fast Thermal Response NTC Temperature Sensor IP68 TPE Injection Overmolding High Sensitivity And Fast Thermal Response NTC Temperature Sensor IP68 TPE Injection Overmolding High Sensitivity And Fast Thermal Response NTC Temperature Sensor IP68 TPE Injection Overmolding

Large Image :  High Sensitivity And Fast Thermal Response NTC Temperature Sensor IP68 TPE Injection Overmolding

Product Details:
Place of Origin: China
Brand Name: XIXITRONICS
Certification: RoHS , REACH
Model Number: MFT-O Series
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Packaging Details: 10pcs / bundle, 50pcs / bundle
Delivery Time: 7-12 work days
Payment Terms: T/T
Supply Ability: 6 Million Pieces Per Year

High Sensitivity And Fast Thermal Response NTC Temperature Sensor IP68 TPE Injection Overmolding

Description
R 25℃: 2KΩ-2.3 MΩ B Value: 3200-4200K
R Tolerance: 0.5% , 1% , 2% , 3% , 5% B Tolerance: 0.5% , 1% , 2% , 3%
High Light:

TPE NTC Temperature Sensor

,

NTC Temperature Sensor IP68

,

ntc temp sensor IP68

High Sensitivity and Fast thermal response IP68 TPE Injection Overmolding Waterproof Temperature Sensors MFT-O Series



Features:
IP68 Rated , Consistent dimension of molded probe head
TPE Injection Over-molded probe
Proven long term Stability and Reliability
High Sensitivity and Fast thermal response



Applications:
Air-conditioners (room and outdoor air)
Automobile air conditioners & heaters
Electric water boilers and water heater tanks (surface)
Fan heaters



Dimensions:



High Sensitivity And Fast Thermal Response NTC Temperature Sensor IP68 TPE Injection Overmolding 0     High Sensitivity And Fast Thermal Response NTC Temperature Sensor IP68 TPE Injection Overmolding 1



High Sensitivity And Fast Thermal Response NTC Temperature Sensor IP68 TPE Injection Overmolding 2     High Sensitivity And Fast Thermal Response NTC Temperature Sensor IP68 TPE Injection Overmolding 3



Product specification:




Specification

R25℃
(KΩ)

B25/50℃
(K)
Disspation Constant
(mW/℃)
Time Constant
(S)
Operation Temperature
(℃)
XXMFT-O-10-102□ 1 3200




approx. 2.2 typical in still air at 25℃




5 - 7   typical in stirred water





-30~105
XXMFT-O-338/350-202□
2
3380/3500
XXMFT-O-327/338-502□ 5 3270/3380/3470
XXMFT-O-327/338-103□
10
3270/3380
XXMFT-O-347/395-103□ 10 3470/3950
XXMFT-O-395-203□
20
3950
XXMFT-O-395/399-473□ 47 3950/3990
XXMFT-O-395/399/400-503□
50
3950/3990/4000
XXMFT-O-395/405/420-104□ 100 3950/4050/4200
XXMFT-O-420/425-204□ 200 4200/4250
XXMFT-O-425/428-474□
470
4250/4280
XXMFT-O-440-504□ 500 4400
XXMFT-O-445/453-145□ 1400 4450/4530
